Côté d'assemblage | Entrée |
Diamètre intérieur 1 [mm] | 24,5 |
Diamètre extérieur 1 [mm] | 42 |
Hauteur 1 [mm] | 6 |
Matériel | ACM (caoutchouc polyacrylique) |
Type de turbulence | Turbulence à droite |
Protection anti-poussière | avec lamelle de protection anti-poussière |
pour numéro OE | 3211300QAB |
Diamètre intérieur 1 [mm] | 15 |
Diamètre extérieur 1 [mm] | 23 |
Hauteur 1 [mm] | 4 |
Matériel | ACM (caoutchouc polyacrylique) |
Protection anti-poussière | avec lamelle de protection anti-poussière |
Côté d'assemblage | côté frontal |
Diamètre intérieur 1 [mm] | 40 |
Diamètre extérieur 1 [mm] | 52 |
Hauteur 1 [mm] | 7 |
Matériel | FPM (caoutchouc fluoré) |
Type de turbulence | Turbulence à droite |
Protection anti-poussière | avec lamelle de protection anti-poussière |
Diamètre intérieur 1 [mm] | 27 |
Diamètre extérieur 1 [mm] | 42 |
Hauteur 1 [mm] | 6 |
Matériel | ACM (caoutchouc polyacrylique) |
Type de turbulence | Turbulence à droite |
Protection anti-poussière | avec lamelle de protection anti-poussière |
Diamètre intérieur 1 [mm] | 19,8 |
Diamètre extérieur 1 [mm] | 40 |
Hauteur 1 [mm] | 5,5 |
Hauteur 2 [mm] | 8 |
Matériel | ACM (caoutchouc polyacrylique) |
Type de turbulence | Turbulence à droite |
Diamètre intérieur 1 [mm] | 21,5 |
Diamètre extérieur 1 [mm] | 48 |
Hauteur 1 [mm] | 8,4 |
Matériel | ACM (caoutchouc polyacrylique) |
Protection anti-poussière | avec lamelle de protection anti-poussière |
Type de turbulence | Turbulence à gauche |
Diamètre intérieur 1 [mm] | 10 |
Diamètre extérieur 1 [mm] | 18 |
Hauteur 1 [mm] | 5 |
Matériel | ACM (caoutchouc polyacrylique) |
Protection anti-poussière | avec lamelle de protection anti-poussière |
Diamètre intérieur 1 [mm] | 20 |
Diamètre extérieur 1 [mm] | 30 |
Hauteur 1 [mm] | 7 |
Matériel | NBR (caoutchoucs nitrile) |
Diamètre intérieur 1 [mm] | 24,5 |
Diamètre extérieur 1 [mm] | 41 |
Hauteur 1 [mm] | 6 |
Matériel | ACM (caoutchouc polyacrylique) |
Protection anti-poussière | avec lamelle de protection anti-poussière |
Type de turbulence | Turbulence à droite |
Diamètre intérieur 1 [mm] | 26,8 |
Diamètre extérieur 1 [mm] | 41 |
Hauteur 1 [mm] | 7 |
Matériel | ACM (caoutchouc polyacrylique) |
Type de turbulence | Turbulence à droite |
Protection anti-poussière | avec lamelle de protection anti-poussière |
